Model | MAG6404 | |
AUX IN | Input Sensitivity | 300mV±50mV |
Effective Frequency of Line Gain Limit (Frequency response ±3dB) | 40Hz-15kHz | |
THD (1Kz 1/3 rated output voltage) | ≤1% | |
Noise | ≤3mV | |
SNR | ≥70 dB | |
AUX OUT | Output Sensitivity | 1.1V±0.2V |
Frequency Response | 40Hz-16kHz | |
Distortion | ≤1% | |
Noise | ≤0.5mV | |
SNR | ≥70 dB | |
Maximum Output Power of Amplifier | Independent Channel Mode (2 channels) | 10W/4Ω |
Maximum Harmonic Distortion of Amplifier | ≤1% | |
Built-in Speaker | 3W/8Ω | |
MIC IN | Input Sensitivity | 5-15 mV |
Frequency Response | 300Hz-3.2kHz | |
Distortion | ≤1% | |
Noise | ≤5 mV | |
SNR (30KHz low pass) | ≥65dB | |
Supply Voltage (DC) | 12V-14V | |
Over Current, Over Heating, Over Voltage and Under Voltage Protection | Satisfied | |
Package Dimensions (L×W×H mm) | 397×236×121 | |
Machine Dimensions (L×W×H mm) | 256×130×57 | |
Gross Weight | 1.9kg | |
Net Weight | 1.2kg | |
